Kyocera ECOSYS P2040dn

2RV/2RW/2RX/2RY/3RA
2-3
(1) Unpacking and checking bundled items
(1-1) Main unit
Take out the main unit and accessories from the packing case.
Remove the tape and cushioning materials for packing from the main unit.
Figure 2-2
Note: Make sure to install the main unit on a level surface.
10
12
9
6
5
4
2
1
11
8
3
7
1. Right upper pad
2. Left upper pad
3. AC power cord
4. Product storage bag
5. Main unit
6. Accessories box
7. Documents
8. Left bottom pad
9. Lower right pad
10. Lower left pad
11. inner frame
12. Outer box
