(4) Periodic maintenance Procedures
CH:Check / CL:Clean / AD:Adjust / LU:Lubrication / RE:Replace
Parts name Parts No. PM maintenance (x1000 counts) Remark
Set UP User Call 100 Please do not use spray containing flamable gas for air-blow or air-brush purposes.
1 IMAGE QUALITY --- CH CH CH
AD AD AD
2 MK-1150
MK-1151
MK-1152
MK-1154
1702RV0NL0
1702RV0JP0
1702RV0US0
1702RV0AS0
RE Drum unit, Developer unit
3 INSIDE OF MACHINE --- CL CL Vacuum: In particular, remove toner and paper dust around imaging and conveying section.
4 PULLEY PICKUP ASSY
PULLEY FEED ASSY
302HN06080
302F906230
CL CL Alcohol or dry cloth if no replacement.
5 ROLLER M/P ASSY 302HS08260 CL CL Alcohol or dry cloth if no replacement.
