Kyocera ECOSYS P2040dn Service Manual

2RV/2RW/2RX/2RY/3RA-3
7-107
(23)Print out is not available from the printer driver setting factor (4)
Printer port supporting the network print is not selected or not set up properly.
(24)Print out is not available from the printer driver setting factor (5)
The incorrect printer driver was selected.
(25)Print out is not available from the printer driver setting factor (6)
Installed printer driver shows "Deleting" and it remains when reinstalling it
Step Check description Assumed cause Measures Reference
1 Correcting the IP address The IP address is not prop-
erly set.
Check if the main unit IP
address displayed on the sta-
tus page and system menu
matches the one at the [Port]
tab of [Printer Properties] of
the PC. If not, correct the IP
address at the PC.
Step Check description Assumed cause Measures Reference
1 Installing the printer driver The incorrect printer driver
is selected.
Select the proper printer
driver. If there is no proper it
on the PC, install the printer
driver which supports the
main unit of the destination of
outputting the data.
Step Check description Assumed cause Measures Reference
1 Cancelling the job The print jobs remain in
the spool inside the printer
driver.
Cancel all the print jobs
spooled in the printer driver.
2 Uninstalling the printer
driver
There is the unused printer
driver.
Delete the unused printer
driver.
3 Restarting the print The system is pausing. Right click the pausing printer
icon and select [Print resum-
ing]. Then, check the ready
port.
4 Correcting the IP address The IP address is not prop-
erly set.
If local network is connected,
check the main unit IP
address with status page.
next, correct the IP address
at the [Port] tab of [Printer
Properties] of the PC.
5 Adding the Standard TCP/
IP port
No Standard TCP/IP port is
available for the main unit
IP address.
Add the main unit IP address
in Standard TCP/IP port and
print Test Page

Kyocera ECOSYS P2040dn Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	6.4 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Duplex print speed (black, normal quality, A4/US Letter)	20 ppm
Printing colors	Black
Maximum duty cycle	50000 pages per month
Replacement cartridges	TK-1160 (7.200 pagina's)
Number of print cartridges	1
Page description languages	PCL 5e, PCL 6, PCL XL, XPS
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.1 W
Power consumption (ready)	8 W
Power consumption (printing)	620 W
Power consumption (PowerSave)	0.8 W
Energy Star Typical Electricity Consumption (TEC)	1.6 kWh/week
Internal memory	256 MB
Processor frequency	800 MHz
Compatible memory cards	SD, SDHC
Sound pressure level (printing)	48.8 dB
Display	LCD
Certification	TÜV/GS, CE
Product color	Black, White
Market positioning	Home & office
Display number of lines	2 lines
Paper input type	Cassette, Paper tray
Total input capacity	250 sheets
Maximum input capacity	850 sheets
Maximum number of input trays	3
Multi-Purpose tray input capacity	100 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Duplex media weight	60 - 163 g/m²
Non-ISO print media sizes	Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Plain paper
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Wi-Fi standards	Not supported
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Kyocera Mobile Print, Mopria Print Service
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Sustainability certificates	Blue Angel, ENERGY STAR
Package depth	516 mm
Package width	500 mm
Package height	400 mm
Package weight	18000 g
Cables included	AC
Included cartridge capacity (black)	3600 pages
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	393 mm
Width	375 mm
Height	272 mm
Weight	14000 g
