Kyocera ECOSYS P2040dn

2RV/2RW/2RX/2RY/3RA
3-1
3 Machine Design
3-1 Cross-section view
(1) Main unit + Paper feeder (option)
Figure 3-1
Paper path
Optical path /
Original path /
Paper path (Option)
8
5
7
9
6
4
3
1
10
2
1. Cassette paper feed
2. MP paper feed section
3. Laser scanner unit
4. Developer unit
5. Drum unit
6. Conveying/Transfer section
7. Fuser section
8. Feedshift and eject section
9. Duplex conveying section
10. Paper feeder (option)
