Kyocera ECOSYS P2040dn Service Manual

2RV/2RW/2RX/2RY/3RA
6-18
6-3 Print event log
Contents
List of the history of paper jams, self-diagnostics errors and toner container replacement is
printed.
Purpose
The machine failure is analyzed by judging the occurrence history of each item.
Method
1.Connects between the main unit and PC (network) via the USB interface connector or network
interface connector.
2.Connects the power cord.
3.Turn the power switch on. Check if it comes to the ready-to-print status.
4.Sends the following Prescribe command from PC to the main unit.
!R!KCFG"ELOG";EXIT;
5.Prints the event log.
Completion
Press the [Stop] key.
Remarks: explaining the set contents (detail of the above procedure 4.).
In the case of connection via the USB interface connector
(1)Save the file describing the Prescribe commands at the above 5.
(2)Sets the shared printer at the sharing tab of the printer properties.
(3)Select the port to connect via USB at [Port] tab.
(Set shared printer name.)
(4)Start up DOS and execute the following command.
copy file name\\computer name\shared printer name
*: Designate the file name saved at (1)
In the case of connection via the network interface connector (using the FTP communication).
(1)Save the file describing the Prescribe commands at the above 4.
(2)Start up DOS and execute the following command.
IP address of ftp printer
*: Both user name and password are left black to proceed.
(3)Next, execute the following command.
put file name
*: Designate the file name saved at (1)
Print event log

Kyocera ECOSYS P2040dn Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	6.4 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Duplex print speed (black, normal quality, A4/US Letter)	20 ppm
Printing colors	Black
Maximum duty cycle	50000 pages per month
Replacement cartridges	TK-1160 (7.200 pagina's)
Number of print cartridges	1
Page description languages	PCL 5e, PCL 6, PCL XL, XPS
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.1 W
Power consumption (ready)	8 W
Power consumption (printing)	620 W
Power consumption (PowerSave)	0.8 W
Energy Star Typical Electricity Consumption (TEC)	1.6 kWh/week
Internal memory	256 MB
Processor frequency	800 MHz
Compatible memory cards	SD, SDHC
Sound pressure level (printing)	48.8 dB
Display	LCD
Certification	TÜV/GS, CE
Product color	Black, White
Market positioning	Home & office
Display number of lines	2 lines
Paper input type	Cassette, Paper tray
Total input capacity	250 sheets
Maximum input capacity	850 sheets
Maximum number of input trays	3
Multi-Purpose tray input capacity	100 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Duplex media weight	60 - 163 g/m²
Non-ISO print media sizes	Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Plain paper
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Wi-Fi standards	Not supported
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Kyocera Mobile Print, Mopria Print Service
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Sustainability certificates	Blue Angel, ENERGY STAR
Package depth	516 mm
Package width	500 mm
Package height	400 mm
Package weight	18000 g
Cables included	AC
Included cartridge capacity (black)	3600 pages
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	393 mm
Width	375 mm
Height	272 mm
Weight	14000 g
