Kyocera ECOSYS P2040dn Service Manual

2RV/2RW/2RX/2RY/3RA-3
7-23
(2-13) Horizontal uneven density
(2-14) Vertical uneven density
Step Check description Assumed cause Measures Reference
1 Cleaning the DS pulley The DS pulleys are dirty. Clean the DS pulleys at both
ends of the developer unit.
2 Replacing the developer
unit
The DS pulleys are faulty. Replace the developer unit.
3 Checking the developer
bias contact
The conduction is not sta-
bilized due to the dirty
developer bias contact.
Clean the developer bias
contact.
4 Replenishing toner in the
developer unit
Toner in the developer unit
is degraded.
Consume degraded toner in
the developer unit with test
prints and replenish the toner.
5 Executing Drum refresh Toner smudges in the
shape of a streak are on
both ends of the drum sur-
face.
Execute Drum refresh.
6 Changing the settings The electric charge
remains on the drum sur-
face due to insufficient dis-
charging.
Execute [MC] at [System
Menu/Counter] key > [Adjust-
ment/Maintenance] > [Ser-
vice Settings] to reduce the
main charger output value.
7 Replacing the drum unit The drum surface is worn
down.
Replace the drum unit.
8 Replacing the LSU The laser emission is
uneven.
Replace the LSU.
Step Check description Assumed cause Measures Reference
1 Executing Drum refresh The drum surface has con-
densation.
Execute Drum refresh.
2 Replacing the LSU The laser is not evenly
emitted from the LSU (The
internal mirror comes off).
Replace the LSU.
3 Cleaning the main charger
wire
Dirt adheres to the main
charger wire.
Clean the main charger wire
surface. If not repaired,
replace the main charger
unit.
4 Replacing the drum unit The drum surface is worn
down.
Replace the drum unit.
5 Replacing the developer
unit
The toner layer on the
developer roller is uneven.
Replace the developer unit.

Kyocera ECOSYS P2040dn Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	6.4 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Duplex print speed (black, normal quality, A4/US Letter)	20 ppm
Printing colors	Black
Maximum duty cycle	50000 pages per month
Replacement cartridges	TK-1160 (7.200 pagina's)
Number of print cartridges	1
Page description languages	PCL 5e, PCL 6, PCL XL, XPS
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.1 W
Power consumption (ready)	8 W
Power consumption (printing)	620 W
Power consumption (PowerSave)	0.8 W
Energy Star Typical Electricity Consumption (TEC)	1.6 kWh/week
Internal memory	256 MB
Processor frequency	800 MHz
Compatible memory cards	SD, SDHC
Sound pressure level (printing)	48.8 dB
Display	LCD
Certification	TÜV/GS, CE
Product color	Black, White
Market positioning	Home & office
Display number of lines	2 lines
Paper input type	Cassette, Paper tray
Total input capacity	250 sheets
Maximum input capacity	850 sheets
Maximum number of input trays	3
Multi-Purpose tray input capacity	100 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Duplex media weight	60 - 163 g/m²
Non-ISO print media sizes	Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Plain paper
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Wi-Fi standards	Not supported
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Kyocera Mobile Print, Mopria Print Service
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Sustainability certificates	Blue Angel, ENERGY STAR
Package depth	516 mm
Package width	500 mm
Package height	400 mm
Package weight	18000 g
Cables included	AC
Included cartridge capacity (black)	3600 pages
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	393 mm
Width	375 mm
Height	272 mm
Weight	14000 g
