Kyocera ECOSYS P2040dn Service Manual

2RV/2RW/2RX/2RY/3RA-3
7-114
(12)Abnormal sound from inside the machine
Dirt at the developer section, Foreign object adhesion or toner aggregation
(13)Abnormal sound from inside the machine
Worn, dirt, foreign object adhesion or waste toner clogging at the drum section
2 Checking the toner
remaining amount
The agitating paddle in the
toner container is warped
or toner amount is low.
Check the toner remaining
amount and replace the toner
container if necessary.
3 Reinstalling / replacing the
toner container
The torque increases due
to the toner condensation.
Shake the toner container
enough and reinstall it. Or,
replace it.
Step Check description Assumed cause Measures Reference
1 Checking the toner supply
opening
The spring for opening and
closing of the toner supply
opening is hooked with the
other parts, or deformed.
Open and close the toner
supply opening manually to
fix the operation.
2 Cleaning the developer
unit
The shaft or the bushing of
the developer roller is dirty
or foreign objects are on
them.
Check if the developer roller
rotates. If not rotating
smoothly, clean the shaft or
the bushing of the developer
roller.
3 Replacing the developer
unit
The torque inside the
developer unit increased
due to the toner condensa-
tion, etc.
Replace the developer unit.
Step Check description Assumed cause Measures Reference
1 Executing Drum refresh Toner is not enough on the
drum.
Execute Drum refresh.
2 Checking the drum unit
and the developer unit
The drum screw does not
properly rotate.
Check if the drum screw
rotates manually. Clean it if
not smoothly rotated. If it is
locked, replace the drum unit.
3 Cleaning and applying the
grease
Foreign objects adhere to
the drum drive gear cogs
or grease is in shortage.
Clean the tooth of the drum
drive gear and apply the
grease to them.
4 Replacing the drum unit The torque inside the drum
unit increased due to the
waste toner clogging, etc.
Replace the drum unit.
Step Check description Assumed cause Measures Reference

Kyocera ECOSYS P2040dn Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	6.4 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Duplex print speed (black, normal quality, A4/US Letter)	20 ppm
Printing colors	Black
Maximum duty cycle	50000 pages per month
Replacement cartridges	TK-1160 (7.200 pagina's)
Number of print cartridges	1
Page description languages	PCL 5e, PCL 6, PCL XL, XPS
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.1 W
Power consumption (ready)	8 W
Power consumption (printing)	620 W
Power consumption (PowerSave)	0.8 W
Energy Star Typical Electricity Consumption (TEC)	1.6 kWh/week
Internal memory	256 MB
Processor frequency	800 MHz
Compatible memory cards	SD, SDHC
Sound pressure level (printing)	48.8 dB
Display	LCD
Certification	TÜV/GS, CE
Product color	Black, White
Market positioning	Home & office
Display number of lines	2 lines
Paper input type	Cassette, Paper tray
Total input capacity	250 sheets
Maximum input capacity	850 sheets
Maximum number of input trays	3
Multi-Purpose tray input capacity	100 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Duplex media weight	60 - 163 g/m²
Non-ISO print media sizes	Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Plain paper
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Wi-Fi standards	Not supported
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Kyocera Mobile Print, Mopria Print Service
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Sustainability certificates	Blue Angel, ENERGY STAR
Package depth	516 mm
Package width	500 mm
Package height	400 mm
Package weight	18000 g
Cables included	AC
Included cartridge capacity (black)	3600 pages
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	393 mm
Width	375 mm
Height	272 mm
Weight	14000 g
