Kyocera ECOSYS P2040dn

2RV/2RW/2RX/2RY/3RA
4-52
9. Remove two screws(M3×10TP)(a).
10. Release two hooks (b) of the upper rear
cover (c) and detach it.
Figure 4-92
11. Pull out the cassette
12. Open the front cover (a).
13. Release four hooks (b) at the front side
of the left cover(a).
Figure 4-93
b
a
b
c
b
b
a
