Kyocera ECOSYS P2040dn

2RV/2RW/2RX/2RY/3RA
4-54
18. Release three hooks by using a flat-
head screwdriver (d).
19. Twist two hooks (c) at the front side of
the right cover (b) to release them and
detach the right cover (b).
Figure 4-96
20. Open the front cover (a) and detach the
strap (b) by using pliers.
21. Remove the stop ring (c).
Figure 4-97
a
c
b
d
c
a
b
