Kyocera ECOSYS P2040dn

2RV/2RW/2RX/2RY/3RA
4-59
34. Detach the eject unit (a) in the direction
of the arrow.
Figure 4-106
35. Release two hooks(b) and detach the
eject unit cover (a).
36. Remove the screw (c) (M3×4P tight).
37. Remove the eject solenoid (d).
38. Check or replace the eject unit(d), and
reattach the parts which are detached in
the original position.
Figure 4-107
a
b
c
a
d
