Kyocera ECOSYS P2040dn Service Manual

2RV/2RW/2RX/2RY/3RA-3
7-67
2 Checking the paper foreign objects are on the
paper.
Remove the paper with for-
eign objects.
3 Checking the paper The paper leading edge is
bent.
Remove the bent paper.
4 Checking the paper The paper is wavy. Correct or replace paper. If
difficult to replace, re-load
paper by switching top and
bottom ends or turning it over.
5 (In case paper hits the FD
guide and jams) Cleaning
the FD guide
Toner is fused on the FD
guide.
Clean the conveying side of
the FD guide.
6 (In case paper jam occurs
at the FD guide) Replacing
paper
The paper curls. Replace with long grain
paper.
7 (In case paper jam occurs
at the FD guide) Replacing
paper
Paper stiffness is lowered
with moisture.
Replace the paper.
8 (In case paper jam occurs
at the FD guide) Checking
paper
The actual paper and the
paper settings (media
type, paper size) do not
match.
Select the proper media type
in the system menu.
9 (In case paper hits the FD
guide and jams) Checking
the conveying path
Paper is caught up at the
FD guide or paper piece.
If there is a paper piece or
foreign object on the convey-
ing side or a burr on the con-
veying side of the FD guide
or on the parts such as actua-
tor, remove it. If not repaired,
replace it.
10 (In case paper hits the FD
guide and jams) Checking
the FD guide
The FD guide does not
operate properly.
Reattach the FD guide and
reconnect the exit unit con-
nector.
11 (In case paper hits the FD
guide and jams) Checking
connection
The connector is not prop-
erly connected or the wire
is faulty.
Clean the terminal of the fol-
lowing wire connectors and
reconnect the connectors. If
there is no continuity, replace
the wire.
• Exit solenoid - Main/engine
PWB (YC1)
12 (In case paper hits the FD
guide and jams) Checking
the exit solenoid
The exit solenoid does not
operate properly.
Reattach the exit solenoid
and reconnect the connector.
If not repaired, replace it.
13 (In case paper hits the FD
guide and jams) Replac-
ing the main/engine PWB
The main/engine PWB is
faulty.
Replace the main/engine
PWB.
Step Check description Assumed cause Measures Reference

Kyocera ECOSYS P2040dn Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	6.4 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Duplex print speed (black, normal quality, A4/US Letter)	20 ppm
Printing colors	Black
Maximum duty cycle	50000 pages per month
Replacement cartridges	TK-1160 (7.200 pagina's)
Number of print cartridges	1
Page description languages	PCL 5e, PCL 6, PCL XL, XPS
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.1 W
Power consumption (ready)	8 W
Power consumption (printing)	620 W
Power consumption (PowerSave)	0.8 W
Energy Star Typical Electricity Consumption (TEC)	1.6 kWh/week
Internal memory	256 MB
Processor frequency	800 MHz
Compatible memory cards	SD, SDHC
Sound pressure level (printing)	48.8 dB
Display	LCD
Certification	TÜV/GS, CE
Product color	Black, White
Market positioning	Home & office
Display number of lines	2 lines
Paper input type	Cassette, Paper tray
Total input capacity	250 sheets
Maximum input capacity	850 sheets
Maximum number of input trays	3
Multi-Purpose tray input capacity	100 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Duplex media weight	60 - 163 g/m²
Non-ISO print media sizes	Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Plain paper
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Wi-Fi standards	Not supported
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Kyocera Mobile Print, Mopria Print Service
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Sustainability certificates	Blue Angel, ENERGY STAR
Package depth	516 mm
Package width	500 mm
Package height	400 mm
Package weight	18000 g
Cables included	AC
Included cartridge capacity (black)	3600 pages
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	393 mm
Width	375 mm
Height	272 mm
Weight	14000 g
