Kyocera FS-3040MFP User Guide

Installation
The installation of the printer is now complete. If prompted, restart your
computer.
Installing in Custom Mode with a Network Connection using
Custom Select
This section describes the custom installation procedure of the driver software
in Windows operating systems using a network connection.
1
Ensure that your printer and computer are connected to a network.
2
On the Installation Method page, select Custom Mode.
3
The Discover Printing System page opens searching for your printing system.
The Discover button is automatically selected. Choose Custom select and
click Next.
4
The Printing System page appears. Select your printing system model from
the list and click Next. If there is only one driver model, this page does not
appear. Proceed to the next step.
5
On the Printer Port page, select the port connected to your printing system, or
add a port connected to your system by clicking Add Port. Click Next.
6
On the Custom Installation page, select the driver and software packages you
want to install from the Driver and Utility tabs, and clear those not intended for
installation. Click Next.
If you only select software packages from the Utility tab, you will skip to the
Confirm Settings page.
7
On the Printer Settings page, you can assign a name for your printing system.
You can also choose to share this printer with others or set this printer as the
default printer. Make your selections, and then click Next.
8
On the Confirm Settings page, click Install if the settings are correct. Click
Back to correct the settings.
Note: If the Hardware Installation warning dialog box appears, click
Continue.
9
The Installation Completed page appears displaying the following driver
options.
Print a test page
This selection verifies a connection with the printer and creates a print out of
the installed driver components.
Show Quick Print Tab
This selection lets you define basic print options into group profiles that can
be accessed easily. The Show Quick Print tab option also appears in the
Administrator Settings in Device Settings.
Enable Status Monitor
KX DRIVER
1-7

Kyocera FS-3040MFP Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Print speed (black, normal quality, A4/US Letter)	40 ppm
Print speed (color, normal quality, A4/US Letter)	23 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Total input capacity	600 sheets
Total output capacity	500 sheets
Maximum input capacity	2100 sheets
Multi-Purpose tray input capacity	100 sheets
Display	LCD
Product color	Black, Grey
Market positioning	Business
Display number of lines	5 lines
Internal memory	256 MB
Maximum print size	216 x 297 mm
Paper tray media types	Bond paper, Envelopes, High resolution paper, Labels, Photo paper, Recycled paper
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Power requirements	120 - 240V
Networking features	Fast Ethernet
All-in-one functions	Copy, Scan
Compatible operating systems	Windows 7/2000/XP/2003/Vista/2008\\r Mac OS 10.x\\r Sun OS4.1.x; Solaris 2.x
Mobile printing technologies	-
Supported network protocols (IPv4)	TCP/IP, IPX/SPX, AppleTalk, NetBEUI
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	1
Power consumption (average operating)	440 W
Scan to	E-mail, FTP, USB
Grayscale levels	256
Image formats supported	JPG, TIF
Document formats supported	PDF
Maximum duty cycle	200000 pages per month
Fax memory	256 pages
Modem speed	33.6 Kbit/s
Fax transmission speed	3 sec/page
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	430 mm
Width	494 mm
Height	448 mm
