2NJ/2RK
2-55
10. Hang the below side of three hooks(a) and then hang the top side of hooks(b) by sliding in the direction of the
arrow.
11. Reattach the left rear cover(d) in the original position with one screw(c)(M3×8).
Figure 2-100
a
d
c
b
