Kyocera TASKalfa 7002i - (6) Feedshift;switchback section; (6-1) Detaching and reattaching the job separator

2WA/2NJ/2RK
4-159
(6) Feedshift/switchback section
(6-1) Detaching and reattaching the job separator
Procedures
1. Pull out the conveying unit (a).
2. Remove the screw (b)(M3x8) and
remove the fuser wire cover (c).
3. Disconnect two connectors (d).
Figure 4-236
a
b
c
d
d
14j0066
