Kyocera TASKalfa 7002i - (7-3) Detaching and reattaching the drum filter and developer filter

2WA/2NJ/2RK
4-49
(7-3) Detaching and reattaching the drum filter and developer filter
Procedures
1. Open the front middle cover (a).
2. Remove the drum filter (c) and devel-
oper filter (d) by pushing the lever (b).
3. Clean the drum filter (c) and developer
filter (d) and then reattach them in the
original position.
Figure 4-62
a
d
c
b
b
