Kyocera TASKalfa 7002i - 3-2 Extension device construction (option); (1) Paper feeder cross-section view (PF-730(B)); (2) Paper feeder cross-section view (PF-740(B))

2WA/2NJ/2RK
3-3
3-2 Extension device construction (option)
(1) Paper feeder cross-section view (PF-730(B))
Figure 3-3
(2) Paper feeder cross-section view (PF-740(B))
Figure 3-4
2
1
Paper path
1. Cassette paper feed section (Cassette 6) 2. Cassette paper feed section (Cassette 7)
1
2
3
Paper path
1. Right paper feed section (Cassette 6)
2. Left paper feed section (Cassette 7)
3. Conveying section
