Kyocera TASKalfa 7002i - Page 109

2NJ/2RK
2-60
15. Insert the mounting plate (a) into the tray stay (B) and secure it with two screws (C) (M4×8).
Figure 2-109
16. Attach the tray cover (b) to the tray stay (c) with four screws (a)(M4×8).
Figure 2-110
a
b
c
c
a
a
b
c
