Kyocera TASKalfa 7002i - Page 112

2NJ/2RK
2-63
5. Latch two hooks (b) on the cut-out (c) of the operation unit, and then attach the numeric keypad (a) with two screws
(d) (M3x8).
Figure 2-116
6. Slid the cover (a) in the direction of the arrow and latch two hooks (b), and secure the screw (c)(M3x8) once
removed in step 2.
Figure 2-117
7. Affix the label (b) on the numeric keypad (a). (Except 120v model)
Figure 2-118
b
a
a
d
d
c
c
a c
b
b
b
a
