Kyocera TASKalfa 7002i - Page 131

2NJ/2RK
2-82
10. Reattach the right upper cover (a) to the main unit in the original position, fasten with one screw(b)(M4×8).
Figure 2-157
11. Reattach the ISU right cover (b) to the direction of the arrow in the original position with two screws (a)(M4×8).
Figure 2-158
12. Reattach the rear operation cover (a) to the direction of the arrow in the original position with one screw (b)(M3×8).
Figure 2-159
b
a
a
b
a
a
b
