Kyocera TASKalfa 7002i - Page 141

2NJ/2RK
2-92
13. Reattach the ISU right cover (b) to the direction of the arrow in the original position with two screws (a)(M4×8).
Figure 2-176
14. Reattach the rear operation cover (a) to the direction of the arrow in the original position with one screw (b)(M3×8).
Figure 2-177
a
b
a
a
b
