Kyocera TASKalfa 7002i - Page 144

2NJ/2RK
2-95
20. Cut the separator cover (b) of the tray lower cover (a) with nippers, etc.
Figure 2-182
21. Attach the tray lower cover (a).
22. Secure the tray lower cover (a) by two pins (b).
Figure 2-183
23. Affix the sheet (b) on the left side of document table (a).
Figure 2-184
a
b
c
B
B
A
A
B
B
A
A
a
b
b
B
B
A
A
B
B
A
A
a
b
