Kyocera TASKalfa 7002i - Page 146

2NJ/2RK
2-97
27. Detach the main unit cover(a) in order from the top.
Figure 2-188
28. Connect one end of the connector (b) of the modular cord (a) to the machine left side.
Figure 2-189
29. Pass the cord through the groove.
Figure 2-190
a
PT1
a
b
