Kyocera TASKalfa 7002i - Page 152

2NJ/2RK
2-103
3. Remove two screws (a)(M3×8), release two hooks (b) and detach the stay (c).
Figure 2-200
4. Pull out the upper cassette (a) from the main unit (b) and remove it in the direction of the arrow.
Figure 2-201
a
c
a
b
b
a
b
