Kyocera TASKalfa 7002i - Page 261

2WA/2NJ/2RK
3-47
Left cassette section
Figure 3-31
1 2 4
3
6
7
8
9
5
12
10
11
1. PF forwarding pulley
2. PF paper feed pulley
3. Separation pulley
4. PF paper feed roller 2
5. PF paper feed pulley
6. PF paper size detection switch 2
7. PF cassette detection switch 2
8. PF upper paper gauge sensor 2
9. PF lower paper gauge sensor 2
10. PF paper sensor 2
11. PF lift sensor 2
12. PF paper feed sensor 2
