2WA/2NJ/2RK-2
3-89
Block diagram
Figure 3-76
YC11-3,4
YC7-5
YC8-1
YC8-6
YC8-3
YC5-3,4
YC7-8
YC7-14
YC8-9
YC15-1,2,4
YC15-5
YC7-10
YC5-2
YC9-5
YC5-5,6,7,8
YC7-17
YC9-3
YC17-4,5,7,8
YC10-2,3
PF conveying sensor 3
YC15-7
PF set switch
PF regist motor
PF eject sensor
PF paper feed
clutch
PF paper feed sensor
PF lift sensor
PF main PWB
PF conveying sensor 1
PF conveying sensor 2
PF lift motor
YC5-3,4
PF lower paper gauge sensor
PF upper paper gauge sensor
PFpaperfeedmotor
PF paper length switch
PF paper width switch
PF multi paper
feed sensor
PF conveying clutch 1
YC7-1
PF top cover
open/close switch
PF feedshift solenoid
PF paper sensor
PF conveying clutch 2
PFconveyingcover
open/closeswitch
