Kyocera TASKalfa 7002i - Page 445

2WA/2NJ/2RK
4-117
11. Remove two screws (a)(M3x8) and
remove the lamp unit (b) from mirror
frame A (c).
Figure 4-175
12. Remove each the screw (a)(M3x8),
remove the front wire presser plate (b)
and the rear wire presser plate (c) from
mirror frame A (d).
13. Detach the mirror frame A (d) from the-
main unit.
Figure 4-176
c
b
a
14j0259
a
a
a
c
b
d
d
d
14j0260
