2WA/2NJ/2RK
4-207
3. Open the document processor.
4. Remove two screws (a)(M3x8) and the
pin (b).
Figure 4-312
5. Slide the document processor (a) in the
direction of the arrow and remove the
hinge (c) from the main unit (b).
6. Detach the document processor by lift-
ing up.
Figure 4-313
ab
a
14j0502
14j0503
a
b
c
c
To Next Page
