2NJ/2RK-1
2-6
5. Check that there is no step on a circle frame of
slope(a).
6. Open the product cover(b).
7. Lift each left and right machine unit, remove the
left bottom pad(c), the right bottom pad(d) and the
product cover(b).
Figure 2-5
8. Travel the machine unit(a) along the slope(b),
move to the floor side.
Figure 2-6
a
a
b
c
d
b
b
a
To Next Page
