Kyocera TASKalfa 7002i - Page 567

2WA/2NJ/2RK
4-239
3. Remove two screws (a)(M3x8) and
remove the PF main PWB (c) from two
holders (b).
4. Check or replace the PF main PWB (c)
and then reattach the parts in the origi-
nal position.
Figure 4-369
a
b
c
a
b
14j0549
