2WA/2NJ/2RK
6-43
Contents
Drive each fan motor.
Contents
Execute to check each fan motor's operation.
Method
1.Press the [Start] key.
2.Select the fan motor to operate.
3.Press the [Start] key.
* :Each operation starts.
* :To stop the operation, press the [Stop] key.
Completion
Press the [Stop] key.
* :The screen for selecting a maintenance item No. is displayed.
U037 Fan motor operation check
(Message: Check Fan Motor Operation)
Items Contents Group
Fuser Cooling Rear fuser fan motor drive B
LSU Cooling LSU fan motor drive B
Exit Cooling Front eject fan motor drive B
Toner Toner fan motor 1,2 drive A
Low Volt Power source fan motor drive A
Exit Rear Cooling Rear eject fan motor drive B
IH PWB IH fan motor drive A
DU Duplex fan motor drive A
IH Coil IF core fan motor drive A
Conv Edge Right front/ Right rear eject fan motor 1 drive A
Fuser Edge Front/ Rear fuser edge fan motor drive A
Toner Blow Exhaust fan motor 3 drive A
GroupA Group A fan motor drive A
GroupB Group B fan motor drive B
