2WA/2NJ/2RK
6-134
Contents
Displays each switch and sensor status of the document processor.
Purpose
Execute to check the operation of switches and sensors of the document processor.
Method
1.Press the [Start] key.
2.Check the switches and sensors by manually turning them on/off.
* :The switch indication is inversed when the switch is detected.
Completion
Press the [Stop] key.
* :The screen for selecting a maintenance item No. is displayed.
U244 DP switch check
(Message: Check DP Switches)
Items Contents
Feed Check DP feed sensor.
Regist Check DP registration sensor.
Timing Check DP timing sensor.
CIS Head Check DP timing sensor.
Set Check DP original detection sensor.
Longitudinal Check DP original length sensor.
Lift U-Limit Check DP lift upper limit sensor.
Lift L-Limit Check DP lift lower limit sensor.
Cover Open Check DP top cover switch.
Open Check DP open/close switch.
Eject Check DP eject sensor.
