KARA
KARAKARA
KARA
®
®®
®
M
MM
MO
OO
ODULAR
DULARDULAR
DULAR WST
WST WST
WST
®
®®
®
SYSTEM
SYSTEM SYSTEM
SYSTEM
rigging procedures using
rigging procedures using rigging procedures using
rigging procedures using
kara
karakara
kara-
--
-minibu
minibuminibu
minibu
VERSION 1.0
KARA_SRM_EN_1-0
w w w . l - a c o u s t i c s . c o m
10
1010
10
5.3 KARA-PULLBACK
The L-ACOUSTICS
®
KARA-PULLBACK rigging
accessory will allow setting the KARA array in a
pullback configuration. It attaches to the bottom
enclosure of the array and to the hook or stinger of
an additional motor.
The KARA-PULLBACK is a plate on which is
attached one shackle fitted with 19 mm/0.75 inch-
diameter bolt and a safety pin.
Figure 5: KARA-PULLBACK rigging accessory
5.4 Flight-case
It is recommended to use a flight-case designed to ship a 3-KARA vertical array. It should contain foam inserts to
prevent array movement and the tray should be fitted with 2 wedges to keep the array vertical.
Figure 6: Recommended flight-case for KARA
Shackle
Tray detail
Complete flight
-
case
Tray supporting a 3
-
KARA array
Wedges
