7.2 Authorized service procedures
7.2.1 Replacement kits and recommended tools
The replacement kits (KR) available for the customer are listed in Table 4. Table 5 is a list of all tools and material
needed for rigging and service (not included).
Service and repair work for any other part must be carried out by an L-ACOUSTICS
®
authorized
representative. Otherwise, the customer may be exposed to dangerous situations and the warranty will
no longer apply.
Table 4: Replacement kits and utilities
Reference Kit description
Kit contents
(fixing material included)
Service procedure
KARA-MINIBU
KR MBUMPLAS Laser support plate 1 plate [7.2.2]
KR CAMAN12L 12 mm shackle with safety pin 2 shackles —
KR PIN621 5/16” R-BLP 10 pins —
KR LOCKBLUE Medium-strength thread-locker (blue) 1 bottle of 50 g —
KARA-MINIBUEX
KR PIN601 5/16” T-BLP 10 pins —
KR SB18iPAT Rubber feet 4 feet [7.2.3]
KARA-ANGARMEX
KR PIN601 5/16” T-BLP 10 pins —
KARA-PULLBACK
KR MAN19L 19 mm shackle with safety pin 4 shackles —
Table 5: Recommended tools (not included)
Electric screwdriver with torque selector (N.m or in.lb
f
)
5 mm hex bit
7 mm hex key
10 mm hex key
T20 Torx
®
bit
T30 Torx
®
bit
