Rigging procedures
Stacking
Attaching K2-JACK stabilizers to L2-CHARIOT/L2D-CHARIOT
Type of deployment stacked array
Rigging accessories K2-JACK
L2-CHARIOT/L2D-CHARIOT
Min number of operators 2
Prerequisite
Each L2/L2D is secured to its chariot. See Securing L2/L2D on L2-CHARIOT/L2D-CHARIOT (p.86).
Procedure
1. Attach the K2-JACK to the L2-CHARIOT/L2D-CHARIOT:
a) Insert the K2-JACK studs through the chariot.
b) Raise and turn the K2-JACK handle to secure the locking system.
L2 owner's manual (EN) version 5.0 129
