Rigging system description
K2-JACK
K2-JACK is a set of two bars and four feet with screw jacks and hand wheels. K2-JACK can be fitted onto L2-
CHARIOT or L2D-CHARIOT to improve stability or to correct floor discrepancies.
During transportation, make sure the bolts are tightened.
bolts (x4)
feet with screw jacks
locking handles
hand wheels
storage position position in use
With K2-JACK, the site angle of L2 or L2D can be adjusted between -8° and 8°.
36 L2 owner's manual (EN) version 5.0
