Rigging system description
L2D-CHARIOT
L2D-CHARIOT is a chariot designed to transport one L2D. It features six ball-locking pins to secure L2D.
Do not move or transport more than one L2D on L2D-CHARIOT.
L2D-CHARIOT is intended for use only with L-Acoustics L2D.
Use with other equipment may result in instability causing injury.
L2D-CHARIOT features red labels for quick identification from L2-CHARIOT.
The default position of L2D-CHARIOT sets L2D at 0° site angle, and with K2-JACK three more positions can set L2D
at 8°, 12°, or 20°. During transportation, the position must be at 0°. Refer to Securing L2/L2D on L2-CHARIOT/L2D-
CHARIOT (p.86) procedure for more information.
Multiple L2D-CHARIOT can be stacked for storage (optionally with L2-CHARIOT, and L2-CHARIOTLID/L2D-
CHARIOTLID). Refer to Stacking multiple L2-CHARIOT/L2D-CHARIOT (p.139).
40 L2 owner's manual (EN) version 5.0
