Flown configurations
The L2 rigging system complies with 2006/42/EC: Machinery Directive. It has been designed following the guidelines of
BGV-C1.
2006/42/EC: Machinery Directive specifies a safety factor of 4 against the rupture. The flown deployments described in
this manual achieve a safety factor of 4 or more.
Refer to Soundvision for the safety factor of a specific deployment.
The safe limit gives the maximum number of elements for which the safety factor is compliant with the 2006/42/EC:
Machinery Directive, within the use defined in this manual and regardless of the other deployment parameters (site
angles, inter-element angles, etc.).
The maximum limit gives the maximum number of elements for which the safety factor can be compliant with the
2006/42/EC: Machinery Directive, when the other deployment parameters provide the best mechanical conditions.
For mixed arrays refer to your Soundvision model.
L2 or L2D or L2 + L2D
configuration rigging accessory safe limit maximum limit
L2-BUMP + L2-BAR (optional)
4 L2 or
3 L2 + 1 L2D
L2-BUMP + LA-RAKMOUNT + 2 L2-
BAR + 2 LA-SLING2T
4 L2 + 1 LA-RAK III or
3 L2 + 1 L2D + 1 LA-RAK III
flown
L2-ROLL 1 L2 or 1 L2D
L2-BUMP + L2-BAR + L2-RIGBAR
2 L2 or
1 L2D
4 L2 or
3 L2 + 1 L2D
2 L2
flown and pullback
L2-RIGBAR x 2
1 L2D 1 L2 + 1 L2D
Other configurations
For other configurations, respect the recommended maximum limit for optimal stability.
L2 or L2D
configuration rigging accessory maximum / safe limit
L2-CHARIOT + K2-JACK 1 L2
stacked
L2D-CHARIOT + K2-JACK 1 L2D
