Corrective maintenance
L2
Introduction
This section contains the following maintenance procedures:
• D/R - Grill (p.149)
• D/R - Fin (p.152)
• D/R - LF speaker (p.153)
• D/R - Side panel (p.154)
• D/R - LC speaker (p.155)
• D/R - Connector plate (p.156)
• D/R - Rear grill (p.157)
• D/R - Trapdoor (p.158)
• D/R - HF driver (p.159)
• D/R - HF diaphragm (p.160)
For advanced maintenance, contact your L-Acoustics representative.
Exploded views
In order to operate, follow the order outlined here. Each assembly refers to the corresponding Disassembly/
Reassembly (D/R) procedure and the necessary repair kit (KR).
Grill Fin
LF speaker
G03647
L2 owner's manual (EN) version 5.0 147
