Rigging system description
L2-BUMPFLIGHT
L2-BUMPFLIGHT is a flightcase for transporting the accessories of the L2 system.
1. 2 CLAMP1000-SINGLE
2. 2 BPCHAIN 1.5T / LA-SLING2T
3. 2 CLAMP1000-BASE
4. 2 L2-RIGBAR
5. 2 DELTA 1.5T
6. 2 CLAMP1000-DUAL (clamps open and towards the center)
7. 1 L2-BUMP
8. 2 LA-RAKMOUNT (or mounted on L2-BUMP)
9. 2 L2-BAR
It is possible to add the L2-BUMPFLIGHTADDLAYER extension in order to
store an additional 2 CLAMP1000-DUAL, 1 L2-BUMP, 2 LA-RAKMOUNT, and
2 L2-BAR.
1
2
3
4
5
6
7
8
9
L2-BUMPFLIGHT with L2-BUMPFLIGHTADDLAYER is the same height as
L2 on L2-CHARIOT with L2-CHARIOTLID or L2D on L2D-CHARIOT with
L2D-CHARIOTLID.
L2 owner's manual (EN) version 5.0 45
