Corrective maintenance
Exploded views
In order to operate, follow the order outlined here. Each assembly refers to the corresponding Disassembly/
Reassembly (D/R) procedure and the necessary repair kit (KR).
Turn L2D upside-down for maintenance
Use L2-ROLL. Refer to Preparing enclosures for maintenance (p.143).
Grill
Fin
Fixed fin
LF speaker
G03647
162 L2 owner's manual (EN) version 5.0
