Source Plate In/Out and Presence
The source plate gripper stage can be commanded to extend outside or to retract back inside the Echo Liquid Handler. Select the
appropriate checkbox.
If the door is closed when the source plate is commanded to extend outside of the Echo Liquid Handler, the door will be opened
first.
When the source plate gripper stage is commanded to retract into the Echo Liquid Handler, the Retract Source Plate Gripper
dialog box will open. Select the plate type being loaded or select None.
Two indicator lights are associated with the source plate. One light reports the current position (in/out) of the source plate gripper
stage, the other light reports the presence of a microplate loaded onto the plategripper.
Figure 76: Retract Source Plate Gripper dialog box
The plate presence indicator has two states:
Gray = Plate not present
Green = Plate present
Destination Plate In/Out and Presence
The destination plate gripper stage can be commanded to extend outside or to retract back inside the Echo Liquid Handler. Select
the appropriate checkbox.
If the door is closed when the destination plate is commanded to extend outside of the Echo Liquid Handler, the door will be
opened first.
When the destination plate gripper stage is commanded to retract into the Echo Liquid Handler, the Retract Dest Plate Gripper
dialog box will open. Select the plate type being loaded or select None.
There are two indicator lights associated with the destination plate. One reports the current position (in/out) of the destination
plate gripper stage. The second reports the presence of a microplate loaded onto the plate gripper.
Figure 77: Retract Dest Plate Gripper dialog box
The plate presence indicator has two states:
Gray = Plate not present
119 PN | 001-11665
USER GUIDE | Echo® 525 Liquid Handler User Guide Echo Liquid Handler Software
