FLIP
®
01.01.2019
English / Englisch
INTRODUCTION
1.1 FEATURES OF THE MACHINE
In figure 1 we have indicated the most important components of
the FLIP
®
. Take your time to become familiar with the machine.
1.2 DESCRIPTION OF THE MACHINE
The FLIP
®
edge-sanding machine works with a sanding plate on
which Velcro sanding discs can be fastened. Traditional sanding
discs fastened with a tension screw can, of course, also be used.
The work zone is protected by the attachment. The fan housing, on
which the electric motor is mounted in vertical position, is located
on the attachment. A motor power cable is used to connect the
machine to the power supply system. The motor switch with ON/OFF
positions is located on the switch box cover of the motor housing.
The machine is moved by means of two guide rollers at the rear
side of the machine. The handles are located on top of the motor.
A rotatable pipe socket is mounted on the rear of the fan housing
which feeds the sanding dust into the dust bag. The dust bag is
connected to the pipe socket via a flange with two quick-release
fasteners. The power cable is attached to the bag’s fixing bracket
with Velcro tape so that it is kept out of the working area of the
machine.
There are three different attachments for the FLIP
®
(part numbers
are in Section 11, Spare parts FLIP
®
):
• short attachment for sanding edges and stairs
• long attachment for sanding edges and below radiators or
similar objects
• attachment for sanding corners (corner attachment)
1.3 PROPER USE AS INTENDED
The FLIP
®
edge-sanding machine is suitable for the dry sanding
of wooden floors, cork floor and wooden stairs in the professional
and rental business sectors.
Any other form of use is not permitted without the approval of the
manufacturer!
Introduction
You have purchased a high-quality product
from LÄGLER
®
. We wish you a great deal
of success with your FLIP
®
. All LÄGLER
®
products are subjected to a thorough
inspection before leaving the factory.
Read these operating instructions
completely before working with the
FLIP
®
for the first time! These operating
instructions include important information
on occupational safety and will provide
you with answers to many questions
so that you can work with the machine
safely and without any problems. If you
cannot find a specific subject in these
operating instructions, please read
the LÄGLER
®
application technique
manual “Sanding of wooden floors”
(http://www.laegler.com) or contact our
service department, your retailer or your
importer.
WARNING!
RISK OF DEATH from electrical shock:
The machine may never be used for wet
processing operations of any kind!
