Lagler Flip - Page 55

FLIP
®
01.01.2019
English / Englisch
SPARE PARTS FLIP
®
Item Part number Description
1 7500.1005.020 Screw
2 0127.1005.000 Spring washer
3 320.20.10.105 Handle FLIP
®
4 320.65.00.100 Universal motor, 230 V / 50 + 60 CPS
322.65.00.100 Universal motor, 110 V / 50 + 60 CPS, USA
5 0988.0016.005 Washer
6 320.10.10.200 Fan wheel
7 320.65.06.100 Motor pulley
8 000.65.60.256 Switch, 230 V / 50 + 60 CPS
000.65.60.156 Switch, 110 + 120 V / 60 + 50 CPS
000.65.62.160 PVC cap with switch frame
9 7500.1005.012 Screw
10 320.65.47.100 Cover with seal
11 320.65.48.105 Cover seal
12 320.65.30.100 Interference-free capacitor, complete
13 320.65.59.100 Latch fastener
14 000.65.42.151 Motor cable 2 x 1.5 mm²
15 000.65.42.153 Motor cable 2 x 1.5 mm², USA
16 000.63.12.071 Rubber tube
17 000.65.84.012 Carbon brush FLIP
®
18 0125.1005.000 Washer
55
ATTENTION: Please specify in inquiries and spare part orders always the serial numbers of your machines ( Section 3.1)!
11
