6: Network Settings
PremierWave® Intelligent Gateway User Guide 53
Table 6-21 Adding a Virtual IP
To Configure Gateway Virtual IP
Using Web Manager
To modify gateway DHCP server information, click Gateway on the menu and select
Configuration > Virtual IP.
Using the CLI
To enter the gateway command level: enable -> config -> gateway
Using XML
Include in your file: <configgroup name = "virtual ip">
DDNS
The PremierWave XC HSPA+ intelligent gateway displays and allows configuration of the DDNS.
Table 6-22 DDNS Configuration
Delete (checkbox) Check the Delete checkbox adjacent to a virtual IP address to be deleted,
clicking the Submit button.
Name The name of an existing virtual IP address.
IP Address An existing virtual IP address to which the LAN IP address is to be mapped.
LAN IP Address An existing LAN IP address to which the virtual IP address is to be mapped.
Virtual IP Settings Description
Name Enter a name of the virtual IP address.
IP Address Enter the virtual IP address to which the LAN IP address is to be mapped.
LAN IP Address Enter the LAN IP address to which the virtual IP address is to be mapped.
Add Click Add after adding new virtual IP information.
DDNS Settings Description
State Select to enable or disable the DDNS state.
Type Select the DDNS IP address type.
User Name Enter a user name for the DDNS account.
Password Enter a password for the DDNS account.
Host Name Specify the host name to be used to update the DDNS.
Interval Indicate the interval of minutes the IP address will be checked. The DDNS
will be updated if the IP address has changed.
Update DDNS (button) Click this button, to save updated configuration information to the Flash.
Virtual IP Settings Description
