12: Network Services
PremierWave® XC HSPA+ Intelligent Gateway User Guide 87
To View or Configure Syslog Settings
Using Web Manager
To configure the Syslog and view current Syslog status, click Syslog in the menu.
Using the CLI
To enter the Syslog command level: enable -> config -> syslog
Using XML
Include in your file: <configgroup name=”syslog”>
HTTP Settings
Hypertext Transfer Protocol (HTTP) is the transport protocol for communicating hypertext
documents on the Internet. HTTP defines how messages are formatted and transmitted. It also
defines the actions web servers and browsers should take in response to different commands.
HTTP Authentication enables the requirement of usernames and passwords for access to the
device.
Table 12-4 HTTP Settings
Severity Log Level
Specify the minimum level of system message the PremierWave device should log
by selecting from the drop-down menu. This setting applies to all syslog facilities.
The drop-down list in the Web Manager is in descending order of severity (e.g.,
Emergency is more severe than Alert.)
HTTP Settings Description
State Select to enable or disable the HTTP server:
Enabled (default)
Disabled
Port Enter the port for the HTTP server to use. The default is 80.
Secure Port Enter the port for the HTTPS server to use. The default is 443. The HTTP
server only listens on the HTTPS Port when an SSL certificate is configured.
Secure Protocols Select to enable or disable the following protocols:
SSL3 = Secure Sockets Layer version 3
TLS1.0 = Transport Layer Security version 1.0. TLS 1.0 is the successor of
SSL3 as defined by the IETF.
TLS1.1 = Transport Layer Security version 1.1
The protocols are enabled by default.
Note: A server certificate and associated private key need to be installed in
the SSL configuration section to use HTTPS.
Secure Credentials
Specify the name of the set of RSA and/or DSA certificates and keys to be
used for the secure connection.
Syslog Settings
(continued)
Description
