A
NATOMY OF THE
U
LTRA
L
YTE
Electronic Copy of LTI’s UltraLyte User’s Manual – 7
th
Edition June 1998
5
Serial Port Connector
The serial port connector allows you to connect the
instrument to a data collector or notebook computer.
The UltraLyte can download speed and range data
in its own format, or in the same format as earlier
Laser Technology speed detection instruments for
compatibility with existing software.
Sighting Scope
Mounted atop the UltraLyte is a single-power
sighting scope. The scope features:
•
an adjustable polarizing light filter to optimize
viewing contrast
•
an in-scope, red aiming dot to help you aim
accurately to the target
•
an in-scope measurement display
Filter adjustment ring
Scope Exterior
87
In-scope Display
