Laser Technology UltraLyte User Manual

R
EALIGNING THE
S
COPE
Electronic Copy of LTI’s UltraLyte User’s Manual – 7
th
Edition June 1998
56
Realignment Procedure
Action Result/Notes
1. Steady the instrument
on a solid base.
Rest the instrument against a solid support that will help keep the aiming dot steady on the target.
2. Expose the adjust-
ment cover screws.
See “Adjustment Screws” above.
3. Press Test/Options
repeatedly until the
test tone screen
displays.
TEST
4. Select a target. The target should be at least 700 feet (200 m) away. See “Target Selection” above.
5. Locate the target. Press and hold the trigger while panning the instrument across the target. When the tone achieves its
highest pitch, the laser light beam is hitting the target.
6. Adjust the scope. Adjust the alignment screws to make the red aiming dot converge with the center of the target.
7. Check the alignment. Use the alignment test procedure on page 46 to double check the alignment. If the instrument doesn’t
pass, repeat the realignment procedure.
8. Secure the instrument. When the instrument passes the alignment test, replace the cover screws.
For Internal Use Only. Not for Distribution.
