Adjusting the Length and Angle
To adjust the length of the stock, loosen the tension
knob and slide the stock back and forth.
To adjust the stock angle, loosen the tension knob
slightly and move the stock up or down. Usually it is
best if the stock is at a slight downward angle.
Refolding the Stock
To refold the stock, extend it to its full length and
reverse the procedure you used to open it. Note that
though the stock can be folded on either side, the
instrument fits in its case only when the stock is fully
extended and folded on the left
side of the
instrument.
Angle
adjustment
LoosenTighten
Length adjustment
