LEGRAND MOSAIC Series User Manual

12












PRESENTATION AND INSTALLATION OF DEVICES
Cat. No. 0 800 53
Cat. No. 0 801 26
Cat. No. 0 802 76
Cat. No. 0 802 53
Cat. No. 0 802 66
Cat. No. 0 802 66
Cat. No. 0 766 60
Cat. No. 0 766 60
Cat. No. 0 802 53
Cat. No. 0 788 16
Cat. No. 0 788 16
Cat. No. 0 766 60
Cat. No. 0 788 36
Cat. No. 0 788 36
Cat. No. 0 766 60
Cat. No. 0 802 86
Flush-mounted wall installation Flush-mounted 2-gang wall installation
Surface-mounted 2-gang wall installation
Surface-mounted wall installation
* Direction: room from which the calls originate
0 766 60: 6DIRECTION* CALL DISPLAY UNIT CONTINUED

LEGRAND MOSAIC Series Specifications

General

Series	MOSAIC
Category	Switch
Brand	LEGRAND
Modular	Yes
Color	White
Material	Plastic
Protection Rating	IP20
Voltage Rating	250 V
Current Rating	10 A
Standards	IEC 60669-1
Installation	Flush mounting
Color Options	White, Black
