LEGRAND MOSAIC Series User Manual

48
TROUBLESHOOTING
FAULT TYPE DIAGNOSTICS
The corridor overdoor light is flashing white quickly Door unit Cat. No. 0 782 04 faulty
The corridor overdoor light is flashing red slowly Corded push-button faulty
The corridor overdoor light is flashing red quickly Biomedical system or bathroom pull-cord faulty
One of the room LED indicators is faintly lit and never goes out Management module is damaged and needs to be replaced
The indicator light on hand-held remote control unit 0 782
01/02/03 does not come on
The indicator light polarity on the magnetic socket is undoubtedly
the wrong way round

LEGRAND MOSAIC Series Specifications

General

Series	MOSAIC
Category	Switch
Brand	LEGRAND
Modular	Yes
Color	White
Material	Plastic
Protection Rating	IP20
Voltage Rating	250 V
Current Rating	10 A
Standards	IEC 60669-1
Installation	Flush mounting
Color Options	White, Black
